Packaging conveying roller
Rollers of different materials
By replacing your warehousing capabilities with the RS-8000 packing a robot parcel sorting system that can carry a very heavy industrial workload in a smart and human-friendly manner, is the way to go. However, covering more distance in less time is what the market demands currently but in addition to that, the RS-8000 will even help you master your fulfillment center's entire workflow.
So, what's the main reason for the RS-8000 being trusted by the logistics managers? It's because of the fact that at present time, warehousing is not only about transporting the goods and it's the supply chain that gets us at the right time, where we need them. Therefore, what really matters to the logistics professionals today is the pinpoint accurate operations, ensuring the safety of their workers, and the ability to have the scale-up flexibility during the peak season with the minimum level of pain and hassle. The RS-8000 is not a disruptive technology that introduces huge changes to your existing environment rather it's a dependable clearing tool that tackles the sorting delays and pushes your operation still further.
Key Features & Advantages
Precision Vision:
UseIntelligence That Evolves：
Through their ongoing learning process, our autonomous decision-making systems can adjust themselves to accommodate the unique assortment of parcels that you handle. It only gets better, faster, and more efficient after each sorting session.
Modular Versatility:
Sustainable Performance:
| Item | Parameter Description |
|---|---|
| Name | Intelligent Scan Code Weighing Volume Measurement All-in-One Machine |
| Measurement Principle | Intelligent Light Curtain Measurement Technology |
| Weighing Accuracy | ±20-50g |
| Minimum Measurable Cargo Weight | 100g |
| Minimum Measurable Cargo Size Range | 50mm (L) × 50mm (W) × 50mm (H) |
| Maximum Measurable Cargo Weight | 50Kg |
| Maximum Measurable Cargo Size Range | 800mm (L) × 800mm (W) × 700mm (H) |
| Dimension Measurement Accuracy | For regular packages: 0-±5mm |
| Equipment Table Size | 1200mm × 800mm (Effective scale surface size) |
| Measurement Speed | 1 to 3 seconds per piece |
| Efficiency | 1200-2400 pieces/hour |
| Equipment Length | 2200mm |
| 1D Barcode Supported | Code128 / Code39 / Code93 / EAN / ITF25 / Codabar |
| 2D Barcode Supported | QR / Datamatrix |
| Barcode Resolution | 10mils / 0.254mm |
| Supported Object Shapes | Regular / Irregular |
| Storage Function | Supports storing photo of each cargo |
| External Support | Windows system; compatible with scanning, weighing, printing; manual data entry supported; provides data interface for system docking |
| Product Composition | Complete machine frame (baked paint or powder coating); Code reading module (industrial camera, industrial lens, data cable, power cable); Weighing module (display instrument, load cell, data cable, power adapter); Measurement module (measurement lens, data cable); Computer set (21.5-inch screen) |
| Usage Scenarios | New product inbound, recommended packaging, logistics warehouse management, truck precise scheduling, outbound freight settlement, etc. |
Factory Introduction
Optimize your warehouse and distribution efficiency with tailored intelligent logistics solutions from Duffy Machinery, a leading material handling specialist based in Fujian, China.Since our establishment in 2007,
we have spent more than 10 years refining intelligent operational systems, with our core team offering 14 years of professional manufacturing experience for each customized project.
With a 35,000㎡ factory and 100+ skilled staff, Our factory is capable of producing 73,000 meters of roller conveyor lines and 2,000 incline conveyors annually; with a total of seven complete production lines,
we ensure stable production and on-time delivery. We have obtained over 40 professional certifications and patents, including ISO9001, CE, EACC and national high-tech enterprise certification, which fully demonstrate our quality strength. Our solutions are widely
recognized by global customers in the Middle East, South America, North America, Southeast Asia and other regions, supported by comprehensive after-sales service to ensure stable and efficient operation.
CASE
In the fiercely competitive domestic express delivery arena, sorting efficiency has become one of the decisive factors for enterprises to improve their service quality. The leading domestic express delivery company, after conducting detailed market analyses, identified Zhangzhou Duffy Machinery Co., Ltd., as the manufacturer offering cross narrowband sorting system and DWS equipment capable of meeting the tight efficiency operational requirements.
Historically, the company relied on traditional sorting which could only process 20000 packages in 8 hours, giving an approximate average capacity of 2500 packages per hour. This approach was personnel intensive and also significantly limited the flow speed of packages and was the main cause of time limitations. Up until now the customer's behavior was influenced by this time rigidness in product flow and their timely delivery became an issue. After the upgrade, thing have changed completely - the number of items sorted per hour went above 10000, which equals the capacity of 4 hours in the past.
Along with the reduction in the duration of the packages' stay at the distribution center and the speeding up of the entire network's flow rhythm, the customers are given a direct experience upgrade. Namely, the time from placing an order to signing for the delivery is substantially shortened, the rate of package damage is decreased significantly due to accurate mechanized operations, and the provision of logistics information is more timely and transparent.
Factory Certificate
We're not just about providing top-notch hardware - we're about giving you complete peace of mind. With 42 prestigious industry certifications like ISO9001, CE, and EACC
Customer concerns (FAQ)
Q1: How many parcels can your Warehouse Robotic Shipping Parcel Sorting Systems sort at most?
A: Our products are quite scalable; the maximum number of parcels they can handle depends on the set-up and ranges from 3,000 to more than 10,000 parcels per hour with an accuracy of 99.9%.
Q2: Is it possible to customize conveyor systems for specific warehouse layouts?
A: Definitely. Since we are direct manufacturers, we can provide you with modular designs such as Telescopic Conveyors and Curved Roller Lines that will optimize your floor space.
Q3: How do your machines assure the safety of fragile shipping parcels?
A: We have installed highly efficient Digital Sensors and Soft-Touch Diverters that control the flow and force so that even the most sensitive articles are sorted without being damaged.
Q4: Does Duffy Machinery support installation and provide after-sales service internationally?
A: We can supply you with full technical documentation as well as video tutorials and, for large-scale Logistics Line Installations, we can also send engineering teams worldwide to assist.
Q5: What kinds of certifications do your material handling equipment have?
A: All and sundry our lines are produced following the ISO9001 Quality Management and are CE certified which means they fulfill the safety requirements and are sufficiently tough to operate in industrial environments.
